3D DEM Explorer V1.0

3D DEM Explorer is a browser-based Digital Elevation Model viewer for exploring GeoTIFF terrain data in interactive 3D.

At a Glance

This project runs directly from the HTML, CSS, and browser-side JavaScript. The workflow is intentionally simple: load a GeoTIFF, adjust the terrain presentation, move through the scene, and export results from the browser.

Tutorial content will be published soon on @the_danish_archaeologist on YouTube, Instagram, and TikTok.

Highlights

• View GeoTIFF elevation data in 3D.
• Switch between grayscale, clay, heatmap, custom heatmap, and satellite imagery.
• Use sky blue, greenscreen, dark mode, or light mode environments.
• Move in ground mode or flight mode.
• Apply smooth terrain, realistic 1:1 scaling, and vertical exaggeration.
• Stream large terrains in chunks to keep massive files usable.
• Export high-resolution PNGs, GLB terrain models, or 4K Video Studio videos.
• Use mobile-friendly touch controls and a slide-out settings drawer.

Controls

Desktop

Other desktop controls include the GeoTIFF file selector, detail-level dropdown, and export buttons in the side panel.

Mobile

• Left joystick for movement, with stronger input producing faster travel.
• Touch-and-drag for looking around without conflicting with movement.
• Settings button for showing or hiding the control drawer.
• Quick actions for upload, PNG export, and Video Studio export.
• Separate jump and down buttons for ground and flight movement.

Detail Levels

Custom mode is also available if you want to enter a target polygon count manually.

Rendering Options

The app shell exposes the following presentation controls:

• Color Style: grayscale, clay, heatmap, custom heatmap, or satellite imagery.
• Background Environment: sky blue, greenscreen, dark mode, or light mode.
• Smooth Terrain: softens harsh surface changes.
• Vertical Exaggeration: increases or reduces terrain relief.
• Realistic Scale: applies a 1:1 scale derived from file metadata when available.
• Chunk Streaming: stream nearby chunks only or load the full DEM chunk set.
• Off-screen Chunk Hiding: reduces clutter when working with large terrains.

File Support

Input: GeoTIFF files (.tif, .tiff). The app uses file metadata and pixel data to estimate scale, shape, and elevation values.

Output: PNG screenshots at high resolution, MP4 videos from Video Studio, and GLB terrain meshes for 3D workflows.

Video Studio

Video Studio is the cinematic export workflow built into the app. It supports portrait or landscape framing, higher-quality supersampling, and configurable encoding settings.

• 9:16 portrait and 16:9 landscape output.
• H.264-compatible export mode and a higher-bitrate H.265 master mode.
• Supersampling where the GPU budget allows it.
• A personal watermark overlay for exported videos.

Local Use

1. Open index.html in a modern browser, or serve the folder with any static web server.
2. Upload a GeoTIFF file from the app UI.
3. Adjust visualization, movement mode, and export settings as needed.

Recommended browsers are current Chromium-based browsers, since the app relies on modern browser APIs for 3D rendering and export features.

Credits

If you need to describe how figures, videos, pictures, or 3D models were made, you can cite this repository or use: DEM-3D Explorer V1.0, Marco Jørgensen (2026).

License

Copyright (c) 2026 Marco Jørgensen

This work, DEM-3D Explorer V1.0, is licensed under the Creative Commons Attribution-NonCommercial 4.0 International License (CC BY-NC 4.0).
